PCB assembly
| Specification | PCBA Capability |
|---|---|
| Placer speed | 600,000 chips/hour |
| Lead Time | 25+ Days (To Be confirmed) |
| SMT | SMT, Through Hole Assembly Single/Double-Side SMT, Single/Double-Sides Mixture Assembly |
| PCB Size | 50mm×50mm ～610mm×508mm |
| PCB Thickness | 0.5mm～4.5mm |
| Min. diameter /space of BGA | 0.2mm/0.35mm |
| Qualifications | ISO 9001:2008 |
| Accuracy | <±30µm, under the condition of 3σ，CPK≥1 |
| Minimum width/space of QFP | 0.15mm/0.25mm |
| Minimum Diameter /Space of BGA | 0.2mm/0.35mm |
| Reliability Test | Flying Probe Test/Fixture test, Impedance Test, Solderability Test, Thermal Shock Test, Hole Resistance Test, and Micor Metallographic Section Analysis, etc. |
OurPCB is focusing on online prototype orders, to meet the requirements for High Quality, Low Cost, Fast Delivery, Easy Ordering from customers around the world.
We can accept 4 kinds of files format (gerber, .pcb, .pcbdoc or .cam file format) for PCB Prototype Manufacturing. We do perform full DRC checks of all Client files and will inform you immediately if we find any problem. We then will work with you to correct the files so they are suitable for manufacturing. Please check our capability overview below for reference. Please contact us if you have a special requirement not listed in the following table.
| Specification | PCB Capability |
|---|---|
| Layer Counts | 1-50 layers |
| Lead Time | Normal: 5-6 Days Expedited: 24-48Hours |
| Materials | FR4, Metal Core, Arlon, Taconic, Nelco, Isola, Halogen Free, Rogers, PTFE, PI,etc. |
| Max. Copper | 12 OZ |
| Finished Board Thickness | 0.1 - 10 mm |
| Min. Line/Track Width&Space | 2.5 mil |
| Qualifications | ISO14001:2015, ISO9001:2015, Certified IATF16949: 2016,Certified |
| Buried / Blind Via (Non-cross) | 0.1 mil |
| Aspect ratio | 20 : 1 |
| Min. Drilling Size(Mechanical) | 0.15 mm |
| Surface Treatment | HASL, Lead free HASL,ENIG(+ G/F). Immersion silver/Tin OSP. ENEPIG. bare copper. |
| Wrap and Twist | ≤0.7% |
| Tolerance PTH/ Pressing fit hole /NPTH | ‡/-0.0762 mm /+/-0.05mm /+/-0.05mm |
| Drill tolerance | +/-2mil |
| BGA pitch | 8mil |
| Laver to layer registration | +/-3mil |
We strive to make the whole assembly process as easy as possible:
- Single Point Source: No need to order bare board PCB from one supplier, solder stencil from another supplier and PCB assembly from yet another supplier.
- We provide prototype promotions and also mass quantity production from one board to thousands of boards.
- We offer rapid turnaround, kit service, turnkey service, harness assembly and box build service.
Flex PCB
- Manufacturing Capability：Conventional Capability；
- Ultimate Capability：Unconventional ability；
- Submit to review beyond these Capabilities.
| Project Item | Normal Capability |
|---|---|
| FPC Base Material (Adhesive) | ShengyiSF302:PI=0.5 mil,1 mil,2 mil;Cu=0.5 oz,1 oz ShengyiSF305:PI=0.5 mil,1 mil,2 mil;Cu=0.33 oz,0.5 oz,1 oz |
| FPC Base Material (Adhesiveless) | SongxiaRF-775/777:PI=1 mil,2 mil,3 mil;Cu=0.5 oz, 1 oz (Ultimate:PI=1 mil,2 mil,3 mil;Cu=2 oz) Xinyang:PI=1 mil, 2 mil;Cu=0.33 oz, 0.5 oz, 1 oz Taihong PI=1 mil, 2 mil;Cu=0.33 oz, 0.5 oz, 1 oz Dubang AP:PI=1 mil, 2 mil, 3 mil, 4 mil;Cu=0.5 oz, 1 oz (Ultimate:PI=1 mil，2 mil，3 mil，4 mil；Cu=2 oz) |
| Layer | 1-4 Layers (Ultimate:5-8 Layers) |
| Thickness of Finished Product (Flex part，no stiffener) | 0.05-0.5 mm (Ultimate:0.5-0.8 mm) |
| Size of Finished Products(Min) | 5 mm*10 mm (Bridgeless)；10 mm*10 mm (Bridge) Ultimate:4 mm*8 mm (Bridgeless)；8 mm*8 mm (Bridge) |
| Size of Finished Products (Max) | 9 inch*14 inch Ultimate:9 inch*23 inch (PI≥1 mil) |
| Impedance Tolerance | Single-Ended：±5Ω(≤50Ω),±10%(＞50Ω) Ultimate:Single-Ended：±3Ω(≤50Ω)，±8%(＞50Ω) |
| Impedance Tolerance | Differencial：±5Ω(≤50Ω),±10%(＞50Ω) Ultimate:Differencial：±4Ω(≤50Ω)，±8%(＞50Ω) |
| Tolerance of Finger Width | ±0.1 mm (Ultimate:±0.05 mm) |
| Min Distance to the Edge of Finger | 8 mil (Ultimate:6 mil) |
| Min Distance between Pads | 4 mil (Ultimate:3 mil) |
| Minimum Laser Hole | 0.1mm |
| Minimum PTH | 0.3mm |
| Min NPTH Tolerance | ±2 mil (Ultimate +0，-2 mil or +2 mil，-0) |
| Solder Bridge Min Width(bottom copper＜2OZ) | 4 mil(Green)，8 mil |
| Solder Bridge Min Width(bottom copper 2-4OZ) | 6 mil，8 mil |
| Overlay Colour | White、Yellow (printed character:White) |
| Type of Surface Treatment | OSP HASL, Lead free HASL, Immersion gold, Hard gold, Immersion silver, OSP |
| Selective Surface Treatment | ENIG+OSP，ENIG+G/F |
